Fixture Details
Features Benefits:
IP65 Rated & NSF Listed Round High Bay; 13,000 31,000 Lumens; Powder coated cold-forged aluminum housing; Remote controlled center mounted sensor option; IK10 impact rated primary polycarbonate lens Clear (std.) Frosted (optional); Optional Diffusers 16 & 22 Frosted Acrylic 14 Aluminum Reflector; 6ft Cord (std.); Mounting Options Cable Hook (std.) Pendant (1/2 threaded hub std.) Surface Mount; Damp & Wet Location 347/480V & Emergency Options; 120-277V Universal Voltage; 0-10V Dimmable Driver (100{d93bac8eefa4ccda5377e7ccd4b2e3661d5680f3108856aec3d7bf5f436c2a8a} 10{d93bac8eefa4ccda5377e7ccd4b2e3661d5680f3108856aec3d7bf5f436c2a8a}); 4000K & 5000K CCT; >80 Color Rendering Index (CRI); Calculated L70 >100,000 Hours; Ambient Temperature Range -40F-122F; 5 Year Warranty (std); 10 Year Warranty Optional; UL Listed for Damp and Wet Locations; DesignLights Consortium Premium Qualified Luminaire
Model Number:
RB3-13L-U-50-REFL90; RB3-13L-U-50-FRL-REFL90; RB3-13L-U-50-FRL-AD22; RB3-13L-U-50-AD22; RB3-13L-U-50-AD16; RB3-13L-U-50; RB3-13L-U-50-FRL; RB3-19L-U-50; RB3-19L-U-50-FRL-AD22; RB3-19L-U-50-FRL-AD16; RB3-19L-U-50-FRL-REFL90; RB3-19L-U-50-REFL90; RB3-19L-U-50-AD22; RB3-19L-U-50-AD16; RB3-19L-U-50-FRL; RB3-25L-U-50; RB3-25L-U-50-FRL-AD22; RB3-25L-U-50-FRL-REFL90; RB3-25L-U-50-REFL90; RB3-25L-U-50-AD22; RB3-25L-U-50-FRL; RB3-31L-U-50; RB3-31L-U-50-FRL-AD22; RB3-31L-U-50-FRL-REFL90; RB3-31L-U-50-REFL90; RB3-31L-U-50-AD22; RB3-31L-U-50-FRL
